Bus push button with 8 control buttons and eight feedback LEDs

In the Nikobus system the bus push buttons are the information transmitters. Each bus push button has a unique address and must not be reset. A bus push button is clicked onto a wall-mounted printed circuit board; contact springs connect the parts. This bus push button has 8 control buttons and eight feedback LEDs A central plate and faceplate in the colour of your choice must be ordered separately.

Bus push button with 8 control buttons and eight feedback LEDs.

• Function: Bus push button with integrated bus coupling which sends a telegram. Can be installed on wall-mounted printed circuit board using a click mechanism. Can be dismantled without undoing bus wiring. Bus push button with its own unique address of 22 bit per control button. The function is determined via software or via a selection procedure on the control module.
• Number of control buttons: 8 control buttons
• Number of leds: eight feedback LEDs
• Infra-red: 4 x 4 or 10 x 4 channels for IR remote control, depending on the type.
• Infra-red address: different addresses
• Wiring technique: 2-wire technology
• Input voltage: 9 Vdc (SELV, safety extra-low voltage)
• Marking: CE
